Extreme Networks BlackDiamond 8800 Series 48-Port GbE Switch Modul G48T 41511

Technische Daten

Gerätetyp

Ethernet Switch Modul

Formfaktor

Plug-In Modul

Data Link Protokoll

Ethernet, Fast Ethernet, Gigabit Ethernet

Remote Management Protokoll

CLI, SNMP, MIB, RMON, BootP, DHCP,

Switching-Kapazität

Max. 48 Gbps

Data Transfer Rate

1000 Mbps

Leistungsmerkmale/Features

Autosensing, Autonegotiating, half/full-Duplex, MDI-X,
Flow Control , Spanning-Tree Protocol, Link Aggregation, VLAN Support, RADIUS, TACACS+, SSHv2, QoS, CoS,
IGMP v1/v2 Snooping, LACP, Port Mirroring, Jumbo Frame

Schnittstellen/Interface

48 x 10Base-T/100Base-TX/1000Base-T - RJ45 Ports

Kompatibilität/Compatibility

BlackDiamond 8800 Series

Standards

IEEE 802.1D (STP)
IEEE 802.1X (Security)
IEEE 802.3 (Ethernet)
IEEE 802.3ad (Link Aggregation)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3ab (1000BASE-T)
IEEE 802.3x (Flow Control)
EN 55022, UL 1950, FCC Part 15 Class A, EN 55024,
UL 60950, VCCI Class A, CE Marking, RoHS
